Galvanized Steel Roller
0 ₫
The Galvanized Steel Roller is our most popular and widely preferred product line, designed to meet the vast majority of cargo transport needs in industrial environments. Manufactured from galvanized steel tubing, it offers effective resistance against scratches and rust under standard operating conditions, ensuring a long service life.
This is the cost-optimal choice for roller conveyor and belt conveyor systems, specifically engineered for transporting cartons, parcels, and pallets in warehouses, logistics centers, and production lines.
Technical Specifications:
- Tube Material: Galvanized Steel Pipe
- Tube Diameter (Ø): 38mm / 42mm / 49mm / 60mm / 76mm (Or custom upon request)
- Wall Thickness: 1.2mm – 2.0mm (Or custom upon request)
- Shaft Material: Steel
- Shaft Diameter (Ø): 10mm – 15mm (Or custom upon request)
- Shaft End Type: Spring Loaded, Internal Thread (Female), Milled Flats, Hexagonal (Optional)
- Bearing Type: Pressed Bearing Housing / Machined Bearing Housing (Optional Steel or Plastic cup; compatible with SKF, NSK bearings…)
- Load Capacity: 15 – 100 kg/roller (Depending on specifications)
- Origin: Machined at TVN Mech
Please fill out the form below, and we will contact you with a detailed quotation!
Reviews (1)
1 review for Galvanized Steel Roller
Add a review
Ordering Guide
Thank you for your interest in the custom machining services at TVN Mech. Below are the ordering process and some important notes to ensure a smooth transaction.
Ordering Process:
- Submit Request: Please provide detailed information about the product you need machined (technical drawings, images, dimensions, materials, quantity) via Hotline/Zalo: 0946 507 052.
- Consultation & Quotation: The TVN Mech engineering team will review your request, advise on the optimal solution, and send a detailed quotation within 24 business hours.
- Order Confirmation & Deposit: Once the solution is agreed upon, please confirm the order and proceed with the deposit (typically 30-50% of the total order value).
- Production: TVN Mech will proceed with manufacturing the product according to the confirmed technical specifications.
- Inspection & Delivery: Upon completion, products will undergo quality control. We will notify you for final acceptance/inspection and proceed with delivery.
- Delivery Time: These are custom-made products and are not in stock. Production and delivery time ranges from 1-7 business days depending on the complexity and quantity.
- Pricing: Product prices depend on material specifications and order quantity. Please contact us directly via Hotline/Zalo 0946 507 052 for the most accurate quote.
- Return Policy: As these are custom-manufactured items based on specific requirements, we do not accept returns unless there is a technical defect caused by TVN Mech manufacturing incorrectly against the agreed specifications.
- Detailed Policies: For more information regarding payment, shipping, and warranty regulations, please visit our Sales Policy page.
